Centrifugal Fans
-
![Forward Curve Centrifugal Fan]()
Forward Curve Centrifugal FanForward curve centrifugal fan is directly connected with the motor with no transmission loss. Forward curved blades enables the blower to transport large volume of air with low to moderate...read more -
![Belt Drive Forward Curve Blower]()
Belt Drive Forward Curve BlowerBelt drive forward curve blower’s impeller is driven by the motor utilizing a set of transmission, including belt, belt pulley, belt guard, etc. Our blower has large volume with relative low...read more -
![Dust Collector Exhaust Fan]()
Dust Collector Exhaust FanDust collector exhaust fan can be direct connected to the motor with a shaft, or it could be driven by the motor involving the transmission part. Other than that, it might also use a coupling...read more -
![Fume Exhaust Blower]()
Fume Exhaust BlowerFume exhaust blower is available in direct drive, belt drive or coupling drive arrangement. It shall be decided on the client’s actual application. This type of fan is designed to exhaust large...read more -
![Paint Room Exhaust Fan]()
Paint Room Exhaust FanPaint room exhaust fan could utilize both direct drive or belt drive way, which is up to client’s installation requirements. This type of fan is designed to exhaust spray air in the paint room at...read more -
![Belt Drive Fan]()
Belt Drive FanBelt drive fan’s impeller is connected to the motor with the bearing and the bearing housing with a shaft. And it is driven by the motor through the belt rotation. This arrangement is designed to...read more -
![Direct Drive Fan]()
Direct Drive FanDirect drive fan’s impeller is directly connected to the motor with a shaft, thus it is driven by the motor directly, hence, it has 0 mechanic efficiency loss and shares 100% mechanic efficiency....read more -
![Double Inlet Forward Curved Centrifugal Fan]()
Double Inlet Forward Curved Centrifugal FanDouble inlet forward curved centrifugal fan is known for its high air-volume and high efficientcy. It has two inlets and two fan wheels and two bearings on each end. It is also called DIDW fan,...read more -
![Double Inlet Centrifugal Fan]()
Double Inlet Centrifugal FanDouble inlet centrifugal fan is known for its high air-volume. It has two inlets and two fan wheels and two bearings on each end. It is also called DIDW fan, which is known for its high...read more -
![Seal Air Blower]()
Seal Air BlowerEquipped with the sealing part, seal air blower could be used in environment with flammable, explosive or toxic gas achieving the goal of 0 leakage. There are 3 types of sealing designs, carbon...read more -
![High Pressure Centrifugal Fan]()
High Pressure Centrifugal FanHigh pressure centrifugal fan is applied in the heavy dust environment or in the system where the resistance is pretty high. High pressure fan is equipped with high power motor to provide enough...read more -
![Moderate Pressure Centrifugal Fan]()
Moderate Pressure Centrifugal FanMechanical seal and packing seal are utilized between fan components to enhance sealing performance and fulfill sealing requirements. Our high-power layer cutting machine enables us to precisely...read more
Centrifugal Fans Specifications
|
Wheel Design: |
Backward Inclined-Airfoil |
|
Design Features: |
VOLUME - to 140,000 CFM (238,000m3/hr) PRESSURES - to 14" WG (3,490 Pa) TEMPERATURES - to 200°F (90°C) 16 SIZES - 12"- 73" (305mm-1,854mm) ARRANGEMENTS - 4M, 4V, 4S, 4D, 4R, 9M, 9V, 9S, 9D, 9R |
|
Available Materials of Construction: |
Carbon Steel |
Types of Centrifugal Fans available
Forward Curved Centrifugal Fans
They are also called squirrel cage fans. The reason is that the wheel of the fan is in the form of a squirrel cage wheel. Their structure is very fragile and is not suitable for industrial purposes.
Inline Centrifugal Fans
They have a rugged construction that consists of a tube casing and a backward inclined wheel. They are mainly for square ducts where they act as clean air boosters for exhaust and supply systems.
Backward Inclined Centrifugal Fans
Backward inclined centrifugal fans consist of three different blade designs. These blade designs are curved airfoil, curved single-thickness, and flat single-thickness blades.
Airfoil Centrifugal Fans
Airfoil centrifugal fans have high airflow volume. They have lower power consumption characteristics. They also consist of a leading edge.
Our Certificates
We're professional centrifugal fans manufacturers and suppliers in China, specialized in providing high quality products and service. We warmly welcome you to buy customized centrifugal fans at competitive price from our factory.
Backward curved plug exhaust fan
